DIP Switch

Category Series Description Download
Rotary ERD9

SMD & Through Hole(Dip)
Dimension 10*10mm
Pitch:2.54mm
Position:10/16

Rotary ERD

SMD & Through Hole(Dip)
Dimension 10*10mm
Pitch:2.54mm
Position:8/10/16

Rotary ERD7

SMD & Through Hole(Dip)
Dimension 7*7mm
Pitch:2.54mm
Position:8/10/16

Rotary ERD6

SMD & Through Hole(Dip)
Dimension 7*7mm
Pitch:2.54mm
Position:4

Half Pitch EHS

SMD
Top Actuated
Pitch:1.27mm

Half Pitch EHP

SMD
Edge Actuated
Pitch:1.27mm

Auto Inserting EAH

Through Hole(Dip)
上撥式
Pitch:2.54mm

Auto Inserting EAD

SMD
Top Actuated
Pitch:2.54mm

Auto Inserting EAM

Through Hole(Dip)
Top Actuated(End-Stackable)
Pitch:2.54mm

Auto Inserting ESD

SMD
Top Actuated(End-Stackable)
Pitch:2.54mm

Auto Inserting ESL

SMD
Top Actuated(End-Stackable)
J-Hook Type
Pitch:2.54mm

Tri-State ETD

Through Hole(Dip)
Tri-State
Pitch:2.54mm

Tri-State ETA

Through Hole(Dip)
Tri-State / Auto Inserting
Pitch:2.54mm

Tri-State ETS

SMD
Tri-State / Auto Inserting
Pitch:2.54mm

Edge Actuated EPH

Through Hole(Dip)
Piano Type / Auto Inserting
Pitch:2.54mm

Edge Actuated EPG

Through Hole(Dip)
Piano Type / Gold plated
Pitch:2.54mm

Edge Actuated EPS

Through Hole(Dip)
Piano Type / Tin plated
Pitch:2.54mm

Edge Actuated EPA

SMD
Piano Type / Auto Inserting
Pitch:2.54mm

Slide Type EDG

Through Hole(Dip)
Slide Type / Gold plated Pitch:2.54mm

Slide Type EDS

Through Hole(Dip)
Slide Type / Tin plated
Pitch:2.54mm

Slide Type EDG-SRA

Through Hole(Dip)
Slide Type / Gold plated
Right Angle
Pitch:2.54mm

Slide Type EDS-SRA

Through Hole(Dip)
Slide Type / Tin plated
Right Angle
Pitch:2.54mm
